Coaxial Cables > TELESCOPE CABLES
Braiding Types 50 ohms
12D-FB | 10D-FB | 8D-FB | 7D-FB | 5D-FB | |||||||||||
Physical Dimensions | |||||||||||||||
Inner Conductor (Dia. mm) | 4.40 | 3.50 | 2.80 | 2.60 | 1.80 | ||||||||||
Dieelectric (Dia. mm) | 12.40 | 10.00 | 7.80 | 7.30 | 5.00 | ||||||||||
Outer Conductor (Dia. mm) | 13.30 | 11.00 | 8.70 | 8.20 | 5.80 | ||||||||||
Jacket (Dia. mm) | 15.60 | 13.00 | 10.40 | 9.80 | 7.50 | ||||||||||
|
3.40 | 4.10 | - | 5.30 | - | ||||||||||
4.70 | 5.60 | - | 7.30 | - | |||||||||||
5.30 | 6.30 | - | 8.30 | - | |||||||||||
5.80 | 6.90 | 8.80 | 9.10 | 13.00 | |||||||||||
8.50 | 10.20 | - | 13.00 | - | |||||||||||
9.20 | 11.10 | 14.00 | 14.30 | 20.40 | |||||||||||
10.90 | 13.40 | 16.70 | 17.00 | 24.20 | |||||||||||
12.30 | 15.30 | 19.20 | 19.70 | 27.50 | |||||||||||
14.30 | 17.70 | 22.20 | 22.90 | 31.80 | |||||||||||
Inner Conductor Resistance ohms/km | 1.16 | 1.83 | 2.86 | 3.31 | 7.05 | ||||||||||
Insulation Resistance M ohms/km | 1000 | ||||||||||||||
Voltage Withstand (AC V/min) | 1000 | ||||||||||||||
Characterstic Impedance (ohms) | 50 ± 2 | ||||||||||||||
|
20 | ||||||||||||||
18 |
